External Halyard Illuminator
Request project pricing
Project pricing within one business day
Pricing depends on model, finish, power source, and quantity. Tell us about your project and our commercial team responds within one business day with pricing, recommendations, and BABA documentation as needed.
Authorized dealers and lighting reps: contact your FlagCo account manager for program pricing.
Buying for resale? See the Wholesale Partner ProgramThe Illuminator Standard V2 Series External Halyard Flagpole combines premium quality with advanced lighting features, including an integrated Flagpole Beacon for enhanced visibility.
Why the External Halyard Illuminator?
A commercial flagpole and a FlagCo Beacon sold as one matched package, so your flag stays lit after dark without a separate ground light to aim or maintain.
Light From the Top, Aimed at the Flag
The Beacon mounts at the top of the pole in place of the standard truck and ornament, and shines down on the flag. It revolves 359° to follow the flag as the wind shifts, so there is no ground spotlight to aim or reposition. The pole and beacon ship together as a matched package, and the beacon is installed on site when the pole goes up.
Fly the Flag Day and Night
The U.S. Flag Code (4 U.S.C. §6) says the flag may be displayed 24 hours a day when it is properly illuminated during the hours of darkness. The Illuminator makes that easy. Choose 120V AC for a hardwired connection, or 12V DC for solar, where the light turns on at dusk and off at dawn by itself.
External Halyard, Simple to Use
The flag is raised and lowered with an external rope halyard tied off to a 9" cleat at the base. No access door, no key and no winch, so anyone on your staff can handle flag changes.
Commercial-Grade Pole and Beacon
The shaft is 6063-T6 extruded aluminum (ASTM B221) with wind ratings per ANSI/NAAMM FP 1001-07, the same as our full commercial line. The Beacon has a die-cast aluminum, powder-coated housing, a 3000K warm white LED array rated for at least 50,000 hours, and a tempered glass lens. It is Intertek (ETL) listed.
Standard Specifications
Included Components
* The pole and beacon ship together as a matched package. The beacon is installed on site when the pole is erected, and 120V AC connections must be made by a licensed electrician. The beacon revolves 359° to follow the flag as it moves in the wind. Solar power options are available; see Solar Options below.
External Halyard Illuminator: All Configurations
Filter by height or scroll to compare wind ratings. Available in heights from 20' to 40'. Beacon is Intertek (ETL) listed.
| Exposed Height |
Top Dia. |
Butt Dia. |
Wall Thick. |
Color | Voltage | Max Flag Size |
Wind Rating w/ Flag |
Wind Rating No Flag |
SKU |
|---|---|---|---|---|---|---|---|---|---|
| 20' | 3" | 5" | 0.125" | Satin | 120V AC | 4' x 6' | 136 mph | 229 mph | 204715 |
| 20' | 3" | 5" | 0.125" | Satin | 12V DC | 4' x 6' | 136 mph | 229 mph | 204715SOL |
| 20' | 3" | 5" | 0.125" | Anodized Black | 120V AC | 4' x 6' | 136 mph | 229 mph | 212471 |
| 20' | 3" | 5" | 0.125" | Anodized Black | 12V DC | 4' x 6' | 136 mph | 229 mph | 212471SOL |
| 20' | 3" | 5" | 0.125" | Anodized Clear | 120V AC | 4' x 6' | 136 mph | 229 mph | 204716 |
| 20' | 3" | 5" | 0.125" | Anodized Clear | 12V DC | 4' x 6' | 136 mph | 229 mph | 204716SOL |
| 20' | 3" | 5" | 0.125" | Anodized Dark Bronze | 120V AC | 4' x 6' | 136 mph | 229 mph | 204717 |
| 20' | 3" | 5" | 0.125" | Anodized Dark Bronze | 12V DC | 4' x 6' | 136 mph | 229 mph | 204717SOL |
| 20' | 3" | 5" | 0.188" | Satin | 120V AC | 4' x 6' | 182 mph | 287 mph | 204700 |
| 20' | 3" | 5" | 0.188" | Satin | 12V DC | 4' x 6' | 182 mph | 287 mph | 204700SOL |
| 20' | 3" | 5" | 0.188" | Anodized Black | 120V AC | 4' x 6' | 182 mph | 287 mph | 212393 |
| 20' | 3" | 5" | 0.188" | Anodized Black | 12V DC | 4' x 6' | 182 mph | 287 mph | 212393SOL |
| 20' | 3" | 5" | 0.188" | Anodized Clear | 120V AC | 4' x 6' | 182 mph | 287 mph | 204701 |
| 20' | 3" | 5" | 0.188" | Anodized Clear | 12V DC | 4' x 6' | 182 mph | 287 mph | 204701SOL |
| 20' | 3" | 5" | 0.188" | Anodized Dark Bronze | 120V AC | 4' x 6' | 182 mph | 287 mph | 204702 |
| 20' | 3" | 5" | 0.188" | Anodized Dark Bronze | 12V DC | 4' x 6' | 182 mph | 287 mph | 204702SOL |
| 25' | 3" | 5" | 0.125" | Satin | 120V AC | 5' x 8' | 98 mph | 136 mph | 204718 |
| 25' | 3" | 5" | 0.125" | Satin | 12V DC | 5' x 8' | 98 mph | 136 mph | 204718SOL |
| 25' | 3" | 5" | 0.125" | Anodized Black | 120V AC | 5' x 8' | 98 mph | 136 mph | 212491 |
| 25' | 3" | 5" | 0.125" | Anodized Black | 12V DC | 5' x 8' | 98 mph | 136 mph | 212491SOL |
| 25' | 3" | 5" | 0.125" | Anodized Clear | 120V AC | 5' x 8' | 98 mph | 136 mph | 204719 |
| 25' | 3" | 5" | 0.125" | Anodized Clear | 12V DC | 5' x 8' | 98 mph | 136 mph | 204719SOL |
| 25' | 3" | 5" | 0.125" | Anodized Dark Bronze | 120V AC | 5' x 8' | 98 mph | 136 mph | 204720 |
| 25' | 3" | 5" | 0.125" | Anodized Dark Bronze | 12V DC | 5' x 8' | 98 mph | 136 mph | 204720SOL |
| 25' | 3.5" | 6" | 0.188" | Satin | 120V AC | 5' x 8' | 168 mph | 253 mph | 204703 |
| 25' | 3.5" | 6" | 0.188" | Satin | 12V DC | 5' x 8' | 168 mph | 253 mph | 204703SOL |
| 25' | 3.5" | 6" | 0.188" | Anodized Black | 120V AC | 5' x 8' | 168 mph | 253 mph | 212416 |
| 25' | 3.5" | 6" | 0.188" | Anodized Black | 12V DC | 5' x 8' | 168 mph | 253 mph | 212416SOL |
| 25' | 3.5" | 6" | 0.188" | Anodized Clear | 120V AC | 5' x 8' | 168 mph | 253 mph | 204704 |
| 25' | 3.5" | 6" | 0.188" | Anodized Clear | 12V DC | 5' x 8' | 168 mph | 253 mph | 204704SOL |
| 25' | 3.5" | 6" | 0.188" | Anodized Dark Bronze | 120V AC | 5' x 8' | 168 mph | 253 mph | 204705 |
| 25' | 3.5" | 6" | 0.188" | Anodized Dark Bronze | 12V DC | 5' x 8' | 168 mph | 253 mph | 204705SOL |
| 25' | 3.5" | 6" | 0.250" | Satin | 120V AC | 5' x 8' | 197 mph | 287 mph | 204980 |
| 25' | 3.5" | 6" | 0.250" | Satin | 12V DC | 5' x 8' | 197 mph | 287 mph | 204980SOL |
| 25' | 3.5" | 6" | 0.250" | Anodized Black | 120V AC | 5' x 8' | 197 mph | 287 mph | 212392 |
| 25' | 3.5" | 6" | 0.250" | Anodized Black | 12V DC | 5' x 8' | 197 mph | 287 mph | 212392SOL |
| 25' | 3.5" | 6" | 0.250" | Anodized Clear | 120V AC | 5' x 8' | 197 mph | 287 mph | 204981 |
| 25' | 3.5" | 6" | 0.250" | Anodized Clear | 12V DC | 5' x 8' | 197 mph | 287 mph | 204981SOL |
| 25' | 3.5" | 6" | 0.250" | Anodized Dark Bronze | 120V AC | 5' x 8' | 197 mph | 287 mph | 204982 |
| 25' | 3.5" | 6" | 0.250" | Anodized Dark Bronze | 12V DC | 5' x 8' | 197 mph | 287 mph | 204982SOL |
| 30' | 3" | 5" | 0.125" | Satin | 120V AC | 6' x 10' | 78 mph | 96 mph | 204721 |
| 30' | 3" | 5" | 0.125" | Satin | 12V DC | 6' x 10' | 78 mph | 96 mph | 204721SOL |
| 30' | 3" | 5" | 0.125" | Anodized Black | 120V AC | 6' x 10' | 78 mph | 96 mph | 212490 |
| 30' | 3" | 5" | 0.125" | Anodized Black | 12V DC | 6' x 10' | 78 mph | 96 mph | 212490SOL |
| 30' | 3" | 5" | 0.125" | Anodized Clear | 120V AC | 6' x 10' | 78 mph | 96 mph | 204722 |
| 30' | 3" | 5" | 0.125" | Anodized Clear | 12V DC | 6' x 10' | 78 mph | 96 mph | 204722SOL |
| 30' | 3" | 5" | 0.125" | Anodized Dark Bronze | 120V AC | 6' x 10' | 78 mph | 96 mph | 204723 |
| 30' | 3" | 5" | 0.125" | Anodized Dark Bronze | 12V DC | 6' x 10' | 78 mph | 96 mph | 204723SOL |
| 30' | 3.5" | 6" | 0.188" | Satin | 120V AC | 6' x 10' | 122 mph | 197 mph | 204706 |
| 30' | 3.5" | 6" | 0.188" | Satin | 12V DC | 6' x 10' | 122 mph | 197 mph | 204706SOL |
| 30' | 3.5" | 6" | 0.188" | Anodized Black | 120V AC | 6' x 10' | 122 mph | 197 mph | 210656 |
| 30' | 3.5" | 6" | 0.188" | Anodized Black | 12V DC | 6' x 10' | 122 mph | 197 mph | 210656SOL |
| 30' | 3.5" | 6" | 0.188" | Anodized Clear | 120V AC | 6' x 10' | 122 mph | 197 mph | 204707 |
| 30' | 3.5" | 6" | 0.188" | Anodized Clear | 12V DC | 6' x 10' | 122 mph | 197 mph | 204707SOL |
| 30' | 3.5" | 6" | 0.188" | Anodized Dark Bronze | 120V AC | 6' x 10' | 122 mph | 197 mph | 204708 |
| 30' | 3.5" | 6" | 0.188" | Anodized Dark Bronze | 12V DC | 6' x 10' | 122 mph | 197 mph | 204708SOL |
| 30' | 3.5" | 6" | 0.250" | Satin | 120V AC | 6' x 10' | 150 mph | 229 mph | 210849 |
| 30' | 3.5" | 6" | 0.250" | Satin | 12V DC | 6' x 10' | 150 mph | 229 mph | 210849SOL |
| 30' | 3.5" | 6" | 0.250" | Anodized Black | 120V AC | 6' x 10' | 150 mph | 229 mph | 212391 |
| 30' | 3.5" | 6" | 0.250" | Anodized Black | 12V DC | 6' x 10' | 150 mph | 229 mph | 212391SOL |
| 30' | 3.5" | 6" | 0.250" | Anodized Clear | 120V AC | 6' x 10' | 150 mph | 229 mph | 210850 |
| 30' | 3.5" | 6" | 0.250" | Anodized Clear | 12V DC | 6' x 10' | 150 mph | 229 mph | 210850SOL |
| 30' | 3.5" | 6" | 0.250" | Anodized Dark Bronze | 120V AC | 6' x 10' | 150 mph | 229 mph | 210851 |
| 30' | 3.5" | 6" | 0.250" | Anodized Dark Bronze | 12V DC | 6' x 10' | 150 mph | 229 mph | 210851SOL |
| 35' | 3.5" | 6" | 0.156" | Satin | 120V AC | 6' x 10' | 87 mph | 116 mph | 204724 |
| 35' | 3.5" | 6" | 0.156" | Satin | 12V DC | 6' x 10' | 87 mph | 116 mph | 204724SOL |
| 35' | 3.5" | 6" | 0.156" | Anodized Black | 120V AC | 6' x 10' | 87 mph | 116 mph | 212478 |
| 35' | 3.5" | 6" | 0.156" | Anodized Black | 12V DC | 6' x 10' | 87 mph | 116 mph | 212478SOL |
| 35' | 3.5" | 6" | 0.156" | Anodized Clear | 120V AC | 6' x 10' | 87 mph | 116 mph | 204725 |
| 35' | 3.5" | 6" | 0.156" | Anodized Clear | 12V DC | 6' x 10' | 87 mph | 116 mph | 204725SOL |
| 35' | 3.5" | 6" | 0.156" | Anodized Dark Bronze | 120V AC | 6' x 10' | 87 mph | 116 mph | 204726 |
| 35' | 3.5" | 6" | 0.156" | Anodized Dark Bronze | 12V DC | 6' x 10' | 87 mph | 116 mph | 204726SOL |
| 35'Popular | 3.5" | 7" | 0.188" | Satin | 120V AC | 6' x 10' | 127 mph | 187 mph | 204709 |
| 35'Popular | 3.5" | 7" | 0.188" | Satin | 12V DC | 6' x 10' | 127 mph | 187 mph | 204709SOL |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Black | 120V AC | 6' x 10' | 127 mph | 187 mph | 212407 |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Black | 12V DC | 6' x 10' | 127 mph | 187 mph | 212407SOL |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Clear | 120V AC | 6' x 10' | 127 mph | 187 mph | 204710 |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Clear | 12V DC | 6' x 10' | 127 mph | 187 mph | 204710SOL |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Dark Bronze | 120V AC | 6' x 10' | 127 mph | 187 mph | 204711 |
| 35'Popular | 3.5" | 7" | 0.188" | Anodized Dark Bronze | 12V DC | 6' x 10' | 127 mph | 187 mph | 204711SOL |
| 35' | 3.5" | 8" | 0.250" | Satin | 120V AC | 6' x 10' | 181 mph | 249 mph | 210852 |
| 35' | 3.5" | 8" | 0.250" | Satin | 12V DC | 6' x 10' | 181 mph | 249 mph | 210852SOL |
| 35' | 3.5" | 8" | 0.250" | Anodized Black | 120V AC | 6' x 10' | 181 mph | 249 mph | 212386 |
| 35' | 3.5" | 8" | 0.250" | Anodized Black | 12V DC | 6' x 10' | 181 mph | 249 mph | 212386SOL |
| 35' | 3.5" | 8" | 0.250" | Anodized Clear | 120V AC | 6' x 10' | 181 mph | 249 mph | 210853 |
| 35' | 3.5" | 8" | 0.250" | Anodized Clear | 12V DC | 6' x 10' | 181 mph | 249 mph | 210853SOL |
| 35' | 3.5" | 8" | 0.250" | Anodized Dark Bronze | 120V AC | 6' x 10' | 181 mph | 249 mph | 204992 |
| 35' | 3.5" | 8" | 0.250" | Anodized Dark Bronze | 12V DC | 6' x 10' | 181 mph | 249 mph | 204992SOL |
| 40' | 3.5" | 7" | 0.156" | Satin | 120V AC | 8' x 12' | 87 mph | 122 mph | 204727 |
| 40' | 3.5" | 7" | 0.156" | Satin | 12V DC | 8' x 12' | 87 mph | 122 mph | 204727SOL |
| 40' | 3.5" | 7" | 0.156" | Anodized Black | 120V AC | 8' x 12' | 87 mph | 122 mph | 212474 |
| 40' | 3.5" | 7" | 0.156" | Anodized Black | 12V DC | 8' x 12' | 87 mph | 122 mph | 212474SOL |
| 40' | 3.5" | 7" | 0.156" | Anodized Clear | 120V AC | 8' x 12' | 87 mph | 122 mph | 204728 |
| 40' | 3.5" | 7" | 0.156" | Anodized Clear | 12V DC | 8' x 12' | 87 mph | 122 mph | 204728SOL |
| 40' | 3.5" | 7" | 0.156" | Anodized Dark Bronze | 120V AC | 8' x 12' | 87 mph | 122 mph | 204729 |
| 40' | 3.5" | 7" | 0.156" | Anodized Dark Bronze | 12V DC | 8' x 12' | 87 mph | 122 mph | 204729SOL |
| 40'Popular | 3.5" | 8" | 0.188" | Satin | 120V AC | 8' x 12' | 123 mph | 177 mph | 204712 |
| 40'Popular | 3.5" | 8" | 0.188" | Satin | 12V DC | 8' x 12' | 123 mph | 177 mph | 204712SOL |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Black | 120V AC | 8' x 12' | 123 mph | 177 mph | 212401 |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Black | 12V DC | 8' x 12' | 123 mph | 177 mph | 212401SOL |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Clear | 120V AC | 8' x 12' | 123 mph | 177 mph | 204713 |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Clear | 12V DC | 8' x 12' | 123 mph | 177 mph | 204713SOL |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Dark Bronze | 120V AC | 8' x 12' | 123 mph | 177 mph | 204714 |
| 40'Popular | 3.5" | 8" | 0.188" | Anodized Dark Bronze | 12V DC | 8' x 12' | 123 mph | 177 mph | 204714SOL |
| 40' | 3.5" | 8" | 0.250" | Satin | 120V AC | 8' x 12' | 146 mph | 207 mph | 204993 |
| 40' | 3.5" | 8" | 0.250" | Satin | 12V DC | 8' x 12' | 146 mph | 207 mph | 204993SOL |
| 40' | 3.5" | 8" | 0.250" | Anodized Black | 120V AC | 8' x 12' | 146 mph | 207 mph | 212373 |
| 40' | 3.5" | 8" | 0.250" | Anodized Black | 12V DC | 8' x 12' | 146 mph | 207 mph | 212373SOL |
| 40' | 3.5" | 8" | 0.250" | Anodized Clear | 120V AC | 8' x 12' | 146 mph | 207 mph | 204994 |
| 40' | 3.5" | 8" | 0.250" | Anodized Clear | 12V DC | 8' x 12' | 146 mph | 207 mph | 204994SOL |
| 40' | 3.5" | 8" | 0.250" | Anodized Dark Bronze | 120V AC | 8' x 12' | 146 mph | 207 mph | 204995 |
| 40' | 3.5" | 8" | 0.250" | Anodized Dark Bronze | 12V DC | 8' x 12' | 146 mph | 207 mph | 204995SOL |
Wind ratings per ANSI/NAAMM FP 1001-07, from the FlagCo Cut Sheet Builder. "Wind Rating w/ Flag" assumes the recommended flag size shown. Each pole ships as a matched package with a FlagCo Beacon with gold ball (External Beacon on 20' and 25', External Beacon Plus on 30' to 40'; 120V AC, or 12V DC for solar), rope halyard and 9" cleat, stainless steel snap hooks, cast aluminum flash collar, and galvanized steel ground sleeve. The beacon mounts at the top of the pole in place of the standard truck and ornament and is installed on site.
Trusted by Schools, Hospitals & Government Facilities
What Our Customers Say
Frequently Asked Questions
How does the Illuminator work, and how is the beacon installed?
The External Halyard Illuminator is a commercial flagpole and a FlagCo External Beacon sold as one matched package. The beacon mounts at the top of the pole in place of the standard truck and ornament, shines down on the flag, and revolves 359° to follow the flag as the wind shifts. It ships with the pole and is installed on site when the pole goes up. It comes pre-wired, with a lead the length of the pole plus 10 feet.
Should I choose 120V AC or solar?
Can I fly the American flag at night with this pole?
What wind speed can these flagpoles withstand, and what size flag can I fly?
It depends on the height, butt diameter and wall thickness. For example, a 25′ pole with a 6″ butt is rated 168 mph with a flag in 0.188″ wall and 197 mph in 0.250″ wall. A 40′ pole with an 8″ butt and 0.188″ wall is rated 123 mph with a flag. The table above lists the rating with and without a flag, and the recommended flag size, for every configuration: 4′ x 6′ on 20′, 5′ x 8′ on 25′, 6′ x 10′ on 30′ and 35′, and 8′ x 12′ on 40′. Not sure what your site needs? Look up the design wind speed for your ZIP code with our Wind Speed by ZIP tool, then pick a pole in the table that meets it.
Do I need a foundation? What's included?
Yes. These poles are set in a concrete foundation. Every pole ships with a 16-gauge hot dip galvanized steel ground sleeve with a grounding spike and a 1/4″ steel base plate with a 1/4″ steel support plate. Set depth is 10% of the exposed height: 2′ for a 20′ pole, 2.5′ for 25′, 3′ for 30′, 3.5′ for 35′ and 4′ for 40′. For 120V AC poles, plan the conduit entry and electrical rough-in before the foundation is poured. We send ground sleeve installation instructions that show where the conduit comes in.
How long does shipping take?
Beacons have a production lead time of 15 business days from order confirmation and deposit. After production, standard LTL freight typically takes 2 to 4 weeks. An expedited dedicated truck (1 to 3 days) and same-day local delivery within a 4-hour drive of Acworth, GA are also available. Call 800-962-0956 for freight options and cost to your address, or see our Standard Lead Times page.
Built by People Who Know Flagpoles
FlagCo has been designing, engineering, and manufacturing aluminum flagpoles in Acworth, Georgia since 1989. Our team can help you pick the right height, wall thickness, and halyard system for your site.
Not Sure Which Configuration You Need?
Call our flagpole specialists for a free consultation. We'll walk you through sizing, wind load requirements, and installation planning. Or look up the design wind speed for your project ZIP code first, then pick the pole that meets it in the table above.
